SMT Hot Sale Lead Free SMD Reflow Soldering Ovens(Jaguar R12)
keywords: reflow oven, smd machine,smt machine,solder machine,smd soldering machine,automatic soldering machine,smt machines, led soldering machine, auto soldering machine, smt production line, smt automation, pcb assembly machine, led assembly machine,pcb assembling machine,pick and place soldering machine
Specification:
Introduction:
1.Windows XP system with English and Chinese is easy to learn how to operate and can be change any time.
2. The digital control system adopted with PLC and Modular circuit to stabilized and accurate of repetitive precision.
3. Intelligent diagnosis system (IDS) has the function of trouble remind, alarm, list-out and saving data.
4. Temperature and blower speed can be controlled independently, to meet the high-precision requirements.
5.Effective heating zone length, the heat conduction in full uniform distribution, greatly improving the heating efficiency.
6.Forced cooling system with efficient cooling speed suits all different kinds of lead-free soldering paste.
7.PLC and PID closed loop control to achieve high precision temperature control and repeatable profiles.
8. Standard 12 couples of up and down zones with patented air management system to make hot air convection more efficient and faster thermal compensation.
9.The rail is dealt with hardened process to make it more stability.
10.Nitrogen with machine is option.
keywords: reflow oven, smd machine,smt machine,solder machine,smd soldering machine,automatic soldering machine,smt machines, led soldering machine, auto soldering machine, smt production line, smt automation, pcb assembly machine, led assembly machine,pcb assembling machine,pick and place soldering machine
Specification:
| Model | JAGUAR R12 | |
| Heating System | Number of heating zones | UP 12/BOTTOM 12 |
| Number of cooling zones | 2 | |
| Length of heating zones | 4600mm | |
| Heating mode | hot air | |
| Cooling Mode | Air Oven:Forced air; Nitrogen Oven: Water Chiller | |
| Exhaust Volume | 10m³/min * 2 exhausts | |
| Conveyor System | Max. Width of PCB | 450mm |
| Mesh belt width | 500mm | |
| Transmission Direction | L→R(or R→L) | |
| Transmission Net Height | 900±20mm | |
| Transmission type | Mesh and chain | |
| Range of rail width | 0-450mm | |
| Conveyor speed | 0-2000mm/min | |
| Auto/manual Lubrication | standard | |
| Fixed rail side | Front rail fixed(option: rear rail fixed) | |
| Components high | Top and bottom 25mm | |
| Control system | Power supply | 5 line 3 phase 380V 50/60Hz |
| Total power | 60kw | |
| Starting power | 58kw | |
| Normal power consumption | 12KW | |
| Warming time | About 20 mins | |
| Temp. setting range | Room temperature-300ºC | |
| Temp. control method | PID close loop control & SSR driving | |
| Temp. control precision | ±1ºC | |
| Temp. deviation on PCB | ±2ºC | |
| Data storage | Process Data and status storage(80GB) | |
| Nozzle plate | Aluminum Alloy Plate | |
| Abnormal Alarm | Abnormal temp. (extra-high/extra-low temp.) | |
| Board dropped alarm | Tower light:Yellow-warming, Green-normal, Red-abnormal | |
| General | Dimension(L*W*H) | 6000×1400×1550mm |
| Weight | 2800KG | |
| Color | Computer gray | |
1.Windows XP system with English and Chinese is easy to learn how to operate and can be change any time.
2. The digital control system adopted with PLC and Modular circuit to stabilized and accurate of repetitive precision.
3. Intelligent diagnosis system (IDS) has the function of trouble remind, alarm, list-out and saving data.
4. Temperature and blower speed can be controlled independently, to meet the high-precision requirements.
5.Effective heating zone length, the heat conduction in full uniform distribution, greatly improving the heating efficiency.
6.Forced cooling system with efficient cooling speed suits all different kinds of lead-free soldering paste.
7.PLC and PID closed loop control to achieve high precision temperature control and repeatable profiles.
8. Standard 12 couples of up and down zones with patented air management system to make hot air convection more efficient and faster thermal compensation.
9.The rail is dealt with hardened process to make it more stability.
10.Nitrogen with machine is option.
Our services:
Shenzhen Jaguar Automation Equipment Co.,Ltd is one of the leaders in SMT machine in China.
Then what we can do for you if you want to set up a SMT factory?
1. we can provide full SMT solution.
2. we can provode you with top technical support.
3. we have enrich experience on SMT factory set up.
4.we can provide the best professional tech service.
5.we can help you to deal with all the trouble about SMT.
Machine in Stock ready for shipment:
Package detailed as following:
